Sku:
THAT1512S08-U
The THAT1512 is a high performance audio preamplifier suitable for microphone and bus summing applications.
Designed from the ground up in THAT's complementary bipolar, dielectric isolation process, the THAT1512 improves on existing integrated microphone preamps by offering lower noise at low gains, better distortion characteristics, lower power consumption, higher slew rate and bandwidth, and increased output voltage swing.
The parts are fully protected against ESD on all critical pins, and reliability is further enhanced by its reduced power requirements.
In short, the THAT1512 provides superior performance in a popular format at an affordable price.
| Step Size | - |
|---|---|
| Supply Voltage (max) | ±20V |
| Supply Voltage (min) | ±5V |
| Digitally Controllable | No |
| Noise at 0dB Gain | 34nV/√Hz |
| Noise at 60dB Gain | 1nV/√Hz |
| THD plus Noise | 0.001% |
| Bandwidth at 0dB gain | 11MHz |
| Bandwidth at 60dB gain | 1.6MHz |
| Slew Rate | 19V/μs |
| Supply Current | 6mA |
